Microns decide pass/fail — precision isn’t optional; it’s your competitive edge.
You’re not buying a precision vise for its features; you’re investing in reliability and repeatability.
What You Get
- High precision — fewer inspection surprises.
- Efficient setups — faster repeat workflows.
- Stable consistency — reliable batch outcomes.
Key Specs at a Glance
- Jaw width: 100 mm, 125 mm, 160 mm, 200 mm
- Height of jaw: 32 mm, 40 mm, 45 mm, 50 mm
- Max opening: 100 mm, 120 mm, 150 mm, 200 mm
- Parallelism: 0.025 mm
- Material hardness: Available upon request
- Orientation: Flat/upright
Advantages
- Precision-ground surfaces — reduce rework and wear.
- Consistent clamping force — minimizes drift during processes.
- Versatile orientation — adaptable to multiple machine setups.
Models & Dimensions
All dimensions in mm. Weight in kg.
| Order No | Width of Jaw | Height of Jaw | Max. Opening | Weight |
|---|---|---|---|---|
| QM16100 | 100 | 32 | 100 | 17/16 |
| QM16125 | 125 | 40 | 120 | 24/22 |
| QM16160 | 160 | 45 | 150 | 38/36 |
| QM16200 | 200 | 50 | 200 | 56/54 |
Applications
Choose this Precision Machine Vise when your work looks like this:
- Grinding
- CNC machining
- EDM
- Inspection
How to Pick the Right Model (Fast)
- Jaw width (B) — ensure fitment for your application.
- Max opening (Smax) — matches your largest workpiece.
- Overall length (L) & weight — suit your machinery and space.
Not sure? Tell us what you need, and we’ll guide you to the right choice.
