Microns decide pass/fail — precision is non-negotiable.
You’re not buying the QM16N Series for features—you’re investing in reduced rework and consistent accuracy.
What You Get
- Fewer inspection surprises — increase yield and product consistency.
- Faster repeat setups — save time and reduce labor costs.
- More consistent batches — streamline your production flow.
Key Specs at a Glance
- Jaw Width: 80/100/160/200/250 mm.
- Max Opening: 75/100/150/180/215 mm.
- Height of Jaw: 24/100/45/50/50 mm.
- Overall Length: 256/310/410/438/615 mm.
- Orientation Capability: Flat and upright holding.
- Material: High-strength nodular cast iron.
- Guide Hardness: HRC45.
Advantages
- Durability — nodular cast iron resists wear and drift.
- Precision — ensures accurate results and reduces re-indicating effort.
- Ease of Use — quick setups enable smoother process transfers.
- Stability — multi-axis capability supports varied orientations.
Models & Dimensions
All dimensions in mm. Weight in kg.
| Order No. | Width of Jaw | Height of Jaw | Max. Opening | Overall Length |
|---|---|---|---|---|
| QM1680N | 80 | 24 | 75 | 256 |
| QM16100N | 100 | 100 | 100 | 310 |
| QM16160N | 160 | 45 | 150 | 410 |
| QM16200N | 200 | 50 | 180 | 438 |
| QM16250N | 250 | 50 | 215 | 615 |
Applications
Choose QM16N Series when your work looks like this:
- CNC machining
- Grinding
- EDM processes
- Inspection setups
How to Pick the Right Model (Fast)
- Jaw width (B) — choose per your part’s needs.
- Max opening (Smax) — ensure it fits your workpiece.
- Overall length (L) & weight — match your machine’s capacity.
Not sure? Tell us what you need, and we’ll assist.
