In precision machining, microns decide pass or fail.
You’re not buying precision vises for features—you’re procuring repeatability and accuracy to ensure batch success.
What You Get
- Reduced inspection surprises — maintain consistent quality without rework.
- Faster repeat setups — streamline your workflow and save time.
- Consistent batches — achieve high yield every production cycle.
Key Specs at a Glance
- Parallelism: 0.005mm/100mm.
- Squareness: 0.005mm.
- Construction: high-quality steel.
- Movable jaw section: Configurable.
- Orientation capability: upright and flat.
- Additional specs: Available upon request.
Advantages
- High parallelism — minimizes wear and drift during multi-process transfers.
- Quality materials — prolong vise life, reducing need for frequent replacements.
- Stable holding — reduces re-indicating time in complex setups.
- Quick clamping — improves throughput in high-pressure environments.
Models & Dimensions
All dimensions in mm. Weight in kg.
| Order No. | L | B | H | Weight |
|---|---|---|---|---|
| ZQ8400-I | 140 | 105 | 65 | 3.5 |
| ZQ8401-I | 160 | 125 | 65 | 4.2 |
Applications
Choose Precision Modular Vises when your work looks like this:
- Grinding
- EDM
- Inspection
- Machining centers
How to Pick the Right Model (Fast)
- Jaw width (B) — match with your workpiece dimensions.
- Max opening (Smax) — ensure full opening suits your project size.
- Overall length (L) & weight — verify it fits your machine’s capacity.
Not sure? Tell us your project specs for personalized guidance.
